MODEL | Model | PVM210S | PVM210 |
DISPLAY | Panel | 21.5 ” LCD | 21.5 ” LCD |
Physical Resolution | 1920*1080 | 1920*1080 | |
Aspect Ratio | 16:9 | 16:9 | |
Brightness | 1000 cd/m² | 1000 cd/m² | |
Contrast | 1500：1 | 1500：1 | |
Viewing Angle | 170°/170°(H/V) | 170°/170°(H/V) | |
Color Space | 101% Rec.709 | 101% Rec.709 | |
HDR Supported | HLG;ST2084 300/1000/10000 | HLG;ST2084 300/1000/10000 | |
INPUT | SDI | 1 x 3G SDI | - |
HDMI | 1 x HDMI 1.4b | 1 x HDMI 1.4b | |
VGA | 1 | 1 | |
AV | 1 | 1 | |
OUTPUT | SDI | 1 x 3G-SDI | - |
SUPPORTED FORMATS | SDI | 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60… | - |
HDMI | 2160p 24/25/30, 1080p 24/25/30/50 /60, 1080i 50/60, 720p 50/60… | 2160p 24/25/30, 1080p 24/25/30/50 /60, 1080i 50/60, 720p 50/60… | |
AUDIO IN/OUT | Speaker | 2 | 2 |
SDI | 16ch 48kHz 24-bit | - | |
HDMI | 8ch 24-bit | 8ch 24-bit | |
Ear Jack | 3.5mm-2ch 48kHz 24-bit | 3.5mm-2ch 48kHz 24-bit | |
POWER | Input Voltage | DC12-24V | DC12-24V |
Power Consumption | ≤36W (15V) | ≤36W (15V) | |
ENVIRONMENT | Operating Temperature | 0℃~50℃ | 0℃~50℃ |
Storage Temperature | -20℃~60℃ | -20℃~60℃ | |
Dimension | Dimension(LWD) | 524.8*313.3*19.8mm | 524.8*313.3*19.8mm |
Weight | 4.8kg | 4.8kg |
